TML Cable - Type A for Process Water, Type B Drinking Water |
|
Special cable for the permanent use in process water type A - drinking water type B. Adapted to DIN VDE 0250 and DIN VDE 0282.
Application - As connection cable for submersible electric motors (pumpts) for the permanent use in process resp. drinking water up to a temperature of 70°C. In addition DIN VDE 0298 T. 300 has to be respected.
- Excellent insulation properties in water
- Very low water absorption
- Preservation of the mechanical strength
- BAM* certificate VI.31/10904/01 - confirming the suitability of TML type B in drinking water.
Characteristics at 200C:
- Rated voltage Uo/U - 600/1000V
- Maximum admissible operating voltage:
- in 1 ph and 3 ph systems : 720 / 1200V
- in D C systems : 1800 V
- conductor resistance to DIN / VDE 0295
- Test voltage 50Hz, 5 min : 2500 V
Temperature range:
- Maximum admissible conductor
- Temperature in operation 90°C
- Short circuit temperature 250°C
Fixed : -40°C up to + 80°C
In motion : -25°Cup to + 80°C
Tensile stress : maximum 15 N each sq mm conductor cross section
High Temperature Cables : TML Cable - Type A for Process Water, Type B Drinking Water
-
-
No. of cores x cross section mm² |
Copper Content |
Outer Diameter |
Net weight |
Min. value mm |
Max. value mm |
1 x 1.5 |
14.4 |
5.8 |
7.2 |
54 |
1 x 2.5 |
24.0 |
6.4 |
8.0 |
76 |
1 x 4 |
38.0 |
7.4 |
9.0 |
105 |
1 x 6 |
58.0 |
8.0 |
11.0 |
135 |
1 x 10 |
96.0 |
9.8 |
12.5 |
200 |
1 x 16 |
154.0 |
11.0 |
14.5 |
290 |
1 x 25 |
240.0 |
12.5 |
16.5 |
410 |
1 x 35 |
336.0 |
14.0 |
18.5 |
560 |
1 x 50 |
480.0 |
16.5 |
21.0 |
740 |
1 x 70 |
672.0 |
18.5 |
23.5 |
1000 |
1 x 95 |
912.0 |
21.0 |
26.0 |
1300 |
1 x 120 |
1152.0 |
23.5 |
28.5 |
1650 |
1 x 150 |
1440.0 |
26.0 |
31.5 |
2000 |
1 x 185 |
1776.0 |
27.5 |
34.5 |
2500 |
1 x 240 |
2304.0 |
30.5 |
38.0 |
3100 |
1 x 300 |
2880.0 |
33.5 |
41.5 |
3700 |
|
|
|
|
|
2 x 1.5 |
29.0 |
9.0 |
11.5 |
130 |
2 x 2.5 |
48.0 |
10.5 |
13.5 |
190 |
2 x 4 |
77.0 |
12.0 |
15.0 |
260 |
2 x 6 |
115.0 |
13.5 |
18.5 |
350 |
2 x 10 |
192.0 |
18.5 |
24.0 |
550 |
2 x 16 |
307.0 |
21.0 |
27.5 |
900 |
2 x 25 |
480.0 |
25.0 |
31.5 |
1300 |
|
|
|
|
|
3 x 1.5 |
43.0 |
9.6 |
12.5 |
150 |
3 x 2.5 |
72.0 |
11.5 |
14.5 |
220 |
3 x 4 |
115.0 |
13.0 |
16.0 |
340 |
3 x 6 |
173.0 |
14.5 |
20.0 |
480 |
3 x 10 |
288.0 |
20.0 |
25.5 |
750 |
3 x 16 |
461.0 |
22.5 |
29.5 |
1100 |
3 x 25 |
720.0 |
26.5 |
34.0 |
1450 |
3 x 35 |
1008.0 |
29.5 |
38.0 |
2100 |
3 x 50 |
1440.0 |
34.5 |
44.0 |
2800 |
3 x 70 |
2016.0 |
39.0 |
49.5 |
3800 |
3 x 95 |
2736.0 |
44.0 |
54.6 |
4600 |
3 x 120 |
3456.0 |
47.5 |
59.0 |
5400 |
|
|
|
|
|
4 x 1.5 |
58.0 |
10.5 |
13.5 |
190 |
4 x 2.5 |
96.0 |
12.5 |
15.5 |
280 |
4 x 4 |
154.0 |
14.5 |
18.0 |
390 |
4 x 6 |
230.0 |
16.5 |
22.0 |
520 |
4 x 10 |
384.0 |
22.5 |
24.5 |
950 |
4 x 16 |
614.0 |
26.5 |
28.5 |
1400 |
4 x 25 |
960.0 |
32.0 |
34.0 |
1950 |
4 x 35 |
1344.0 |
33.0 |
42.5 |
2700 |
4 x 50 |
1920.0 |
38.0 |
48.5 |
3600 |
4 x 70 |
2688.0 |
43.0 |
54.5 |
4900 |
4 x 95 |
3648.0 |
50.0 |
60.5 |
6200 |
4 x 120 |
4608.0 |
53.0 |
65.5 |
7200 |
|
|
|
|
|
5 x 1.5 |
72.0 |
11.5 |
15.0 |
230 |
5 x 2.5 |
120.0 |
13.5 |
17.0 |
340 |
5 x 4 |
192.0 |
16.0 |
19.5 |
470 |
5 x 6 |
288.0 |
18.0 |
24.5 |
640 |
5 x 10 |
480.0 |
24.0 |
30.5 |
1150 |
5 x 16 |
768.0 |
27.0 |
35.5 |
1700 |
|
|
|
| |
|
|
|
|
|
| |
|
|
